The Stationary Beam Anchor is used in a wide variety of applications as a single-person connection point. The anchor can be installed on beams in both horizontal or vertical orientations. The anchor is lightweight, installs in seconds, and adjusts from 3.5″ to 14″.
Vertical/Stationary Beam Anchor
019-4009
Vertical/Stationary Beam Anchor
019-4009Steel
The Stationary Beam Anchor is used in a wide variety of applications as a single-person connection point. The anchor can be installed on beams in both horizontal or vertical orientations. The anchor is lightweight, installs in seconds, and adjusts from 3.5″ to 14″.
$0.00
Features:
- Easy installation and use
- Lightweight aluminum construction
- Rotating connection point
Related products
-
019-4007
-
021-4044
-
018-4001
Specifications
| Materials: | Aluminum |
| Weight: | 5.8 lbs. (2.6 kg) |
| Beam Flange Width Range: | 3.5"-14" |
| Breaking Strength: | 5,000 lbs. minimum |
| ANSI Weight Capacity: | 130-310 lbs. (59-141 kg) |
| OSHA Weight Capacity: | Up to 420 lbs. (191 kg) |
| ANSI Standards: | Z359.1 |
| OSHA Standards: | 1926.502 |
