Vertical/Stationary Beam Anchor

019-4009

Vertical/Stationary Beam Anchor

019-4009

Steel

The Stationary Beam Anchor is used in a wide variety of applications as a single-person connection point. The anchor can be installed on beams in both horizontal or vertical orientations. The anchor is lightweight, installs in seconds, and adjusts from 3.5″ to 14″.

Features:

  • Easy installation and use
  • Lightweight aluminum construction
  • Rotating connection point
SKU: 019-4009 Categories: , ,

The Stationary Beam Anchor is used in a wide variety of applications as a single-person connection point. The anchor can be installed on beams in both horizontal or vertical orientations. The anchor is lightweight, installs in seconds, and adjusts from 3.5″ to 14″.

Type

Temporary

Submitted Successfully

We will respond soon

Specifications
Materials: Aluminum
Weight: 5.8 lbs. (2.6 kg)
Beam Flange Width Range: 3.5"-14"
Breaking Strength: 5,000 lbs. minimum
ANSI Weight Capacity: 130-310 lbs. (59-141 kg)
OSHA Weight Capacity: Up to 420 lbs. (191 kg)
OSHA Standards: 1926.502, 1910.140, 1910.66
